| Attribute | Value |
|---|---|
| System | 5-axis linkage CNC system |
| Spindle | Imported BT spindle |
| Transmission mode | Rack drive mechanism |
| Control Technology | Bus absolute servo control |
| Material | Steel Frame + Cast Iron Table |
| Warranty | 1 Year |
| Gross power | 57/67kw |
| Multi function processing | Cutting & carving integration |
| Precision machining | High |
| Type | Medium & large stone focus |
| Performance | Strong stability |
| Parameter | Leader1500 | Leader1500CM |
|---|---|---|
| X/Y/Z Travel | 3800 × 2700 × 1500 mm | 3800 × 3500 × 1500 mm |
| A/C Tilt & Rotation | A 0-180°, C ±365° | A 0-180°, C ±365° |
| Blade / Tool Range | Φ350-700 mm | Φ350-700 mm |
| Spindle | 20 kW water-cooled BT40, 0-10 000 rpm | 20 kW water-cooled BT40, 0-10 000 rpm |
| Table Size | 3400 × 2000 mm fixed | 3400 × 2000 mm + Φ50-600 mm rotary axis |
| Max Cylinder Length | -- | 3200 mm |
| Overall Footprint | 6600 × 4000 × 5500 mm | 6600 × 4800 × 5500 mm |
| Power | 31 kW | 34 kW |
| Weight | 9 000 kg | 11 000 kg |
