Zdqj-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite / Marble

1
MOQ
To Be Negotiable
giá bán
Zdqj-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite / Marble
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Bảo hành: 1 năm, một năm, 12 tháng, 18 tháng, 2 năm
Dịch vụ sau bán hàng được cung cấp: Các kỹ sư có sẵn cho máy móc dịch vụ ở nước ngoài, hỗ trợ trực tuyến, hỗ trợ kỹ thuật video, dịch vụ
Cân nặng: 1-5 tấn, 1000kg, 62/65kg, 600kg, 320kg
Tình trạng: Mới
Kích thước (L*W*H): 6000*1400*1550mm, 3500*4000*2500mm, 3250x3450x900mm, 2200*2200*1700,775*270*460mm
Điện áp: 380V, 380V/50Hz, 230V/380V, 220V, tùy chọn
Cách sử dụng: Chế biến gỗ, Cưa cắt gỗ, Cắt gỗ, cưa cắt, Cắt kim loại
Phong cách: Ngang, khác, dọc
Sử dụng: Chỗ gỗ, đá granit và đá cẩm thạch
Tên sản phẩm: Máy cắt bằng gỗ tự động, máy cưa cắt tốc độ cao tự động, máy cắt nước nhỏ, máy cưa tròn tự động, máy
Kiểu: Saw Band, SF606, hoàn toàn tự động, cắt ra, cưa bảng điều khiển bảng
Ứng dụng: Tấm máy cắt gỗ, nhà máy làm việc bằng gỗ, máy cắt đá đá cẩm thạch đá granit, chế biến gỗ, chế biến g
Sức mạnh định mức: 15kw
Tên: Máy cưa băng cắt gỗ, máy cắt bảng tự động bảng điều khiển bằng gỗ, cưa bảng chính xác, cưa băng ghế
Màu sắc: Màu xanh, khách hàng được thiết kế, có thể tùy chỉnh, xanh hoặc màu vàng, màu vàng
Đường kính lưỡi cưa: 300mm(250mm-350mm),450mm,600mm
Từ khóa: Máy cưa cắt tốc độ cao, máy cắt ngang kim loại ngang, máy cưa cắt tự động, cưa băng kim loại
Làm nổi bật:

Granite Stone Bridge Saw Cutting Machine

,

Automatic Stone Bridge Saw Cutting Machine

,

Infrared Bridge Saw Cutting Machine

Thông tin cơ bản
Nguồn gốc: Jinjiang, Phúc Kiến, Trung Quốc
Hàng hiệu: Xianda Machinery
Chứng nhận: CCC, SONCAP, GOST, ISO, CE
Số mô hình: ZDQJ-450
Thanh toán
Thời gian giao hàng: 30 ngày
Điều khoản thanh toán: L/C, D/A, T/T, D/P, Liên minh phương Tây
Khả năng cung cấp: 1000 bộ/năm
Mô tả sản phẩm
ZDQJ-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite/Marble
Basic Information
Model NO.: ZDQJ-450/600/800
Application: Construction, Stone Industry
Source Voltage: 380V
Automation: Automatic
Cutting Ability: High Speed
Control: PLC
Certification: CCC, SONCAP, GOST, ISO, CE
Blade Diameter: Φ300-Φ450
Max Processing Size: 3200*2000*120mm
Dimension of Worktable: 3200*2000mm
Workable Tilting Degree: 0-85°
Worktable Rotation Degree(Optional): 0-90° / 0-360°
Main Motor: 15kw
Gross Motor: 21kw
Water Consumption: 4m3/H
Outline Dimension: 6000*4800*2900mm
Gross Weight: 5250kg
Transport Package: Load in a 20 Feet Container
Specification: 6000*4800*2900mm
Trademark: Xianda
Origin: Jinjiang, Fujian, China
HS Code: 84641090
Production Capacity: 1000 Sets/Year
Zdqj-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite / Marble 0 Zdqj-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite / Marble 1
Product Description
The ZDQJ-450 infrared automatic stone bridge cutting machine comes in three types, featuring PLC system and Human-machine interface. It incorporates ultra-high precision rotary encoder positioning and infrared device, with Chinese & English dual operation language. The machine uses inverter to control left-right feeding, adjusting speed according to stone material, and features hydraulic lifting system equipped through 4 guide posts with unique side beam protection device. Main spare parts utilize imported high-quality materials.
This machine is characterized by high cutting efficiency, precision cutting, excellent stability, and easy operation, making it particularly suitable for high-value granite and large-size marble processing.
Technical Parameters
Parameter Unit ZDQJ-450 ZDQJ-600 ZDQJ-700
Blade diameter mm 300-450 350-600 350-700
Max processing size mm 3200*2000*120 3200*2000*180 3200*2000*230
Dimension of worktable mm 3200*2000 3200*2000 3200*2000
Worktable tilting degree ° 0-85° 0-85° 0-85°
Worktable rotation degree ° 0-90°/0-360° 0-90°/0-360° 0-90°/0-360°
Main motor kw 15 18.5 18.5
Gross motor kw 21 24 24
Water consumption m³/h 4 4 4
Outline dimension mm 6000*4800*2900 6000*4800*3100 6000*4800*3200
Gross weight kg 5250 5500 5750
Xianda Machinery
Zdqj-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite / Marble 2
Fujian Jinjiang Xianda Machinery Co.Ltd was established in 1985 and has been dedicated to the development and production of a series of column making machines, wire saw stone cutting machines, block trimming machines, bridge saw cutting machines, and profiling stone cutting machines.
With the company's rapid development, we have passed ISO9001 verification, CE certification, and won many honorary titles including the International Gold Plant Quality Award. We maintain "Advanced Technology and High Quality" as our aim and have developed a range of 'Xianda' Brand special stone shape processing machines.
Exhibition
Zdqj-450/600/700 Infrared Automatic Stone Bridge Saw Cutting Machine for Granite / Marble 3
Our Service
  • Training for machine installation and operation
  • Engineers available for overseas machinery service
  • 24-hour online after-sales service
For any inquiries or support, please contact our sales department or customer service department at any time.
